Cliquez sur "En savoir plus" pour découvrir toutes les déclinaisons disponibles pour ce produit.
Possibilité adaptateur de réduction double BSP x Métrique en inox.
Implantation A : MBSP
Implantation B : METRIQUE
|
Référence |
Ø Filetage G |
Ø Filetage D |
Longueur | Clé | Pression |
|
1/8 |
10X1 | 25mm | 14mm | 350 bar | |
|
MBSPCT1/8XMI12X1.5 |
1/8 |
12X1.5 |
27.5mm | 17mm | 300 bar |
|
MBSPCT1/4XMI10X1 |
1/4 |
10X1 | 27.5 mm | 19mm | 300 bar |
|
MBSPCT1/4XMI12X1.5 |
1/4 |
12X1.5 | 30 mm | 19mm | 300 bar |
|
MBSPCT1/4XMI14X1.5 |
1/4 |
14X1.5 | 29 mm | 19mm | 300 bar |
|
MBSPCT1/4XMI16X1.5 |
1/4 |
16X1.5 | 32.5 mm | 22mm | 250 bar |
|
1/4 |
18X1.5 | 35 mm | 24mm | 250 bar | |
|
MBSPCT3/8XMI12X1.5 |
3/8 |
12X1.5 | 31.5 mm | 22mm | 280 bar |
|
MBSPCT3/8XMI14X1.5 |
3/8 |
14X1.5 | 32.5 mm | 22mm | 280 bar |
|
MBSPCT3/8XMI16X1.5 |
3/8 |
16X1.5 | 34.5 mm | 22mm | 250 bar |
|
MBSPCT3/8XMI18X1.5 |
3/8 |
18X1.5 | 36.5 mm | 24mm | 250 bar |
|
3/8 |
20X1.5 | 36.5 mm | 27mm | 200 bar | |
|
MBSPCT3/8XMI22X1.5 |
3/8 |
22X1.5 | 37 mm | 27mm | 200 bar |
|
MBSPCT1/2XMI14X1.5 |
1/2 |
14X1.5 | 35 mm | 27mm | 200 bar |
|
MBSPCT1/2XMI16X1.5 |
1/2 |
16X1.5 | 36.5 mm | 27mm | 200 bar |
|
1/2 |
18X1.5 | 38 mm | 27mm | 200 bar | |
|
MBSPCT5/8XMI |
5/8 |
38.5 mm | 30mm | 200 bar | |
|
MBSPCT5/8XMI |
5/8 |
40 mm | 30mm | 200 bar | |
|
MBSPCT3/4XMI |
3/4 |
37.5 mm | 32mm | 200 bar | |
|
MBSPCT3/4XMI |
3/4 |
43 mm | 32mm | 200 bar | |
|
MBSPCT3/4XMI |
3/4 |
40 mm | 32mm | 200 bar | |
|
MBSPCT3/4XMI |
3/4 |
43.5 mm | 32mm | 200 bar | |
|
1" |
42.5 mm | 41mm | 120 bar | ||
|
MBSPCT1"XMI |
1" |
48 mm | 41mm | 120 bar | |
|
MBSPCT1"XMI |
1" |
46 mm | 41mm | 120 bar | |
|
MBSPCT1"XMI |
1" |
50 mm | 41mm | 120 bar | |
|
1"1/4 |
48.5 mm | 50mm | 105 bar | ||
|
MBSPCT1"1/4XMI |
1"1/4 |
50.5 mm | 50mm | 105 bar | |
|
MBSPCT1"1/4XMI |
1"1/4 |
56 mm | 50mm | 105 bar | |
|
MBSPCT1"1/2XMI |
1"1/2 |
51 mm | 55mm | 105 bar | |
|
MBSPCT1"1/2XMI |
1"1/2 |
53 mm | 55mm | 105 bar | |
|
1"1/2 |
59 mm | 55mm | 105 bar | ||
|
MBSPCT1"1/2XMI |
1"1/2 |
57 mm | 55mm | 105 bar | |
|
MBSPCT2"XMI |
2" |
60 mm | 70mm | 70 bar | |
|
MBSPCT2"XMI |
2" |
60.5 mm | 70mm | 70 bar | |
|
1" |
30X1.5 | 48 mm | 41mm | 120 bar |
Détermination d'une pièce selon sont étanchéité cliquez sur le lien pour en savoir plus: Cliquez ici / BSP - Métrique
Application: Utilisation sur multiple implantation, vérin, bloc distributeur, on retrouve ce type de raccord dans divers installation automobile, agricole, travaux publique, industrie. Etanchéité avec bague BS Métrique cône à 60°BSP.
Matière: Acier zingué.
