Référence
|
Ø Filetage
|
Ø Filetage fpp
mm
|
Diamètre intérieur flexible
|
|
DN
|
Pouce
|
Module
|
|
04TJ7 16
|
7/16
|
9.71-20fpp
|
4
|
3/16
|
3
|
|
06TJ7 16
|
7/16
|
9.71-20fpp
|
6
|
1/4
|
4
|
|
06TJ1 2
|
1/2
|
11.12-20fpp
|
6
|
1/4
|
4
|
|
06TJ9 16
|
9/16
|
12.76-18fpp
|
6
|
1/4
|
4
|
|
08TJ1 2
|
1/2
|
11.12-20fpp
|
8
|
5/16
|
5
|
|
08TJ9 16
|
9/16
|
12.76-18fpp
|
8
|
5/16
|
5
|
|
08TJ3 4
|
3/4
|
17.33-16fpp
|
8
|
5/16
|
5
|
|
08TJ5 8
|
5/8
|
14.3-18fpp
|
8
|
5/16
|
5
|
|
10TJ9 16
|
9/16
|
12.76-18fpp
|
10
|
3/8
|
6
|
|
10TJ3 4
|
3/4
|
17.33-16fpp
|
10
|
3/8
|
6
|
|
10TJ5 8
|
5/8
|
14.3-18fpp
|
10
|
3/8
|
6
|
|
10TJ7 8
|
7/8
|
20.26-14fpp
|
10
|
3/8
|
6
|
|
13TJ3 4
|
3/4
|
17.33-16fpp
|
13
|
1/2
|
8
|
|
13TJ7 8
|
7/8
|
20.26-14fpp
|
13
|
1/2
|
8
|
|
13TJ1"1 16
|
1"1/16
|
24.69-12fpp
|
13
|
1/2
|
8
|
|
16TJ7 8
|
7/8
|
20.26-14fpp
|
16
|
5/8
|
10
|
|
19TJ7/8
|
7/8
|
20.26-14fpp
|
16
|
3/4
|
12
|
|
16TJ1"1 16
|
1"1/16
|
24.69-14fpp
|
16
|
5/8
|
10
|
|
19TJ1"1 16
|
1"1/16
|
24.69-14fpp
|
19
|
3/4
|
12
|
|
19TJ1"3 16
|
1"3/16
|
27.87-12fpp
|
19
|
3/4
|
12
|
|
19TJ1"5 16
|
1"5/16
|
31.04-12fpp
|
19
|
3/4
|
12
|
|
25TJ1"1 16
|
1"1/16
|
24.69-14fpp
|
25
|
1"
|
16
|
|
25TJ1"5 16
|
1"5/16
|
31.04-12fpp
|
25
|
1"
|
16
|
|
25TJ1"5 8
|
1"5/8
|
38.98-12fpp
|
25
|
1"
|
16
|
|
32TJ1"5 8
|
1"5/8
|
38.98-12fpp
|
32
|
1"1/4
|
20
|
|
38TJ1"7 8
|
1"7/8
|
45.33-12fpp
|
38
|
1"1/2
|
24
|
|
50TJ2"1 2
|
2"1/2
|
61.2-12fpp
|
50
|
2"
|
32
|
Pour plus d'informations sur comment déterminer votre embout hydraulique, cliquez ici
